Thermopile Power Sensors
<p style="text-align: center;">Sensors incorporating thermopile detectors to measure power of CW and modulated lasers.</p><div style="text-align: center;"><span style="background-color: transparent; color: #000000; float: none; font-size: 12px; font-style: normal; font-weight: 400; text-align: center; text-decoration: none; white-space: normal;">- </span>Range: Approx. 100 µW to 5 kW;<br><span style="background-color: transparent; color: #000000; float: none; font-size: 12px; font-style: normal; font-weight: 400; text-align: center; text-decoration: none; white-space: normal;">- </span>Detector Technology: Thermopile;<br><span style="background-color: transparent; color: #000000; float: none; font-size: 12px; font-style: normal; font-weight: 400; text-align: center; text-decoration: none; white-space: normal;">- </span>Measurement Type: Power (and single pulse Joules);</div>
SKU: 1098328
10 mW to 3W laser power sensor with beam position sensing, 0.25 to 10.6 µm spectral range, 19 mm diameter active area.
SKU: 1098304
10 mW to 10W laser power sensor with beam position sensing, 0.25 to 10.6 µm spectral range, 16 mm diameter active area.
SKU: 1098320
100 mW to 25W laser power sensor with beam position sensing, 0.25 to 10.6 µm spectral range, 19 mm diameter active area.
SKU: 1098341
100 µW to 1W low power sensor, 0.3 to 2 µm spectral range, 19 mm diameter active area with quartz window.
SKU: 1098336
500 µW to 2W range low power sensor, 0.19 to 11 µm spectral range, 19 mm diameter active area.
SKU: 1098329
10 mW to 2W power sensor, 0.25 to 11 µm spectral range, 19 mm diameter active area.
SKU: 1097901
10 mW to 10W power sensor, 0.25 to 11 µm spectral range, 19 mm diameter active area.
SKU: 1098314
100 mW to 30W power sensor, 0.25 to 11 µm spectral range, 19 mm diameter active area.
SKU: 1098338
10 mW to 10W volume-absorbing power sensor, 0.25 to 3 µm spectral range, 19 mm diameter active area.
SKU: 1363752
RS232-enabled 10 mW to 3W laser power sensor with beam position sensing, 0.25 to 10.6 µm spectral range, 19 mm diameter active area.
SKU: 1287077
USB-enabled, 100 µW to 1W low power sensor, 0.3 to 2 µm spectral range, 10 mm diameter active area with quartz window
SKU: 1288992
RS232-enabled, 100 µW to 1W low power sensor, 0.3 to 2 µm spectral range, 10 mm diameter active area with quartz window.
SKU: 1288940
USB-enabled, 300 mW to 100W (intermittent) compact power sensor, 0.19 to 11 µm spectral range, 19 mm diameter active area
SKU: 1317151
RS232-enabled, 300 mW to 150W power sensor, 0.19 to 11 µm spectral range, 50 mm diameter active area.
SKU: 1305568
RS232-enabled, 300 mW to 150W power sensor, UV coating with 0.15 to 1 µm spectral range, 50 mm diameter active area.
SKU: 1409621
5W to 1000W laser power sensor, 0.19 to 11 µm spectral range, BB+ coating, 50 mm diameter active area.
PowerMax-USB PM1K+ Power Sensor
SKU: 1409622
USB-enabled, 5W to 1000W laser power sensor, 0.19 to 11 µm spectral range, BB+ coating, 50 mm diameter active area.
PowerMax-RS PM1K+ Power Sensor
SKU: 1409623
RS232-enabled, 5W to 1000W laser power sensor, 0.19 to 11 µm spectral range, BB+ coating, 50 mm diameter active area.
SKU: 1409627
5W to 3000W laser power sensor, 0.19 to 11 µm spectral range, BB+ coating, 50 mm diameter active area.
PowerMax-USB PM3K+ Power Sensor
SKU: 1409628
USB-enabled, 5W to 3000W laser power sensor, 0.19 to 11 µm spectral range, BB+ coating, 50 mm diameter active area.
PowerMax-RS PM3K+ Power Sensor
SKU: 1409629
RS232-enabled, 5W to 3000W laser power sensor, 0.19 to 11 µm spectral range, BB+ coating, 50 mm diameter active area.
SKU: 1402728
10W to 6000W laser power sensor, 0.19 to 11 µm spectral range, BB+ coating, 50 mm diameter active area.
PowerMax-USB PM6K+ Power Sensor
SKU: 1402729
USB-enabled, 10W to 6000W laser power sensor, 0.19 to 11 µm spectral range, BB+ coating, 50 mm diameter active area.
PowerMax-RS LM-200 (12V DC) Power Sensor
SKU: 2290747
RS232-enabled, 1W to 200W fan-cooled laser power sensor with beam position sensing, 0.25 to 10.6 µm spectral range, 19 mm diameter active area.
PowerMax-USB LM-200 (12V DC) Power Sensor
SKU: 2290746
USB-enabled, 100 mW to 200W fan-cooled laser power sensor with beam position sensing, 0.25 to 10.6 µm spectral range, 19 mm diameter active area.
