Pulse Energy Sensors
<p style="text-align: center;">Sensors incorporating pyroelectric and optical detectors for measuring energy of pulsed lasers up to 10 kHz.</p> <div style="text-align: center;">- Range: Approx. 100 nJ to 15J;<br>- Detector Technology: Pyroelectric & Optical (semiconductor);<br>- Measurement Type: Pulse energy to 10 kHz;</div>
SKU: 1110746
500 µJ to 1J pulse energy sensor, rep. rate up to 1000 pps, MaxBlack coating with 0.19 to 12 µm spectral range, 25 mm diameter active area.
SKU: 1110743
25 µJ to 50mJ pulse energy sensor, rep. rate up to 1000 pps, MaxBlack coating with 0.19 to 12 µm spectral range, 25 mm diameter active area.
SKU: 1110843
10 µJ to 20mJ pulse energy sensor, rep. rate up to 1000 pps, MaxBlack coating with 0.19 to 12 µm spectral range, 10 mm diameter active area.
SKU: 1110855
300 nJ to 600µJ pulse energy sensor, rep. rate up to 1000 pps, MaxBlack coating with 0.19 to 12 µm spectral range, 10 mm diameter active area.
SKU: 1110574
500 µJ - 1J pulse energy sensor, rep. rate up to 10000 pps, metallic coating with 0.19 to 2.1 µm spectral range, 50 mm diameter active area.
SKU: 1110747
50 µJ - 100 mJ pulse energy sensor, rep. rate up to 10000 pps, metallic coating with 0.19 to 2.1 µm spectral range, 25 mm diameter active area.
SKU: 1110856
100 nJ to 200 µJ pulse energy sensor, rep. rate up to 10000 pps, metallic coating with 0.19 to 2.1 µm spectral range, 10 mm diameter active area.
SKU: 1110744
1.5 mJ - 3J pulse energy sensor, rep. rate up to 50 pps, 0.266 to 2.1 µm spectral range, 35 mm diameter max beam size.
SKU: 1144701
1.5 mJ - 3J pulse energy sensor, rep. rate up to 300 pps, 0.19 to 2.1 µm spectral range, 50 mm diameter max beam size.
SKU: 1151431
12 mJ to 15J pulse energy sensor, rep. rate up to 10 pps, 266 nm to 2.1 µm spectral range, 35 mm diameter max beam size.
SKU: 1174756
50 μJ to 100 mJ pulse energy sensor, rep. rate up to 50 pps, 0.19 to 2.1 µm spectral range, 35 mm diameter max beam size.
SKU: 1155722
1 mJ to 3J pulse energy sensor, rep. rate up to 30 pps, 0.5 to 3.0 µm spectral range, 35 mm diameter max beam size.
SKU: 1110577
1.5 mJ to 3J pulse energy sensor, rep. rate up to 20 pps, 0.5 to 2.1 µm spectral range, 12.5 mm diameter max beam size.
J-50MUV-248 w/o Diffuser Energy Sensor
SKU: 1146243
500 µJ to 1J pulse energy sensor, rep. rate up to 200 pps, 0.19 to 2.1 µm spectral range, 50 mm diameter active area.
SKU: 1110572
500 µJ to 1J pulse energy sensor, rep. rate up to 200 pps, 0.19 to 0.266 µm spectral range, 50 mm diameter active area.
SKU: 1146237
125 µJ to 250 mJ pulse energy sensor, rep. rate up to 200 pps, 0.19 to 2.1 µm spectral range, 50 mm diameter active area.
SKU: 1110575
125 µJ to 250 mJ pulse energy sensor, rep. rate up to 200 pps, 0.19 to 0.266 µm spectral range, 50 mm diameter active area.
SKU: 1110745
125 µJ to 250 mJ pulse energy sensor, rep. rate up to 500 pps, 0.19 to 2.1 µm spectral range, 25 mm diameter active area.
SKU: 1110741
50 µJ to 100 mJ pulse energy sensor, rep. rate up to 500 pps, 0.19 to 2.1 µm spectral range, 25 mm diameter active area.
J-10Si-LE Quantum Energy Sensor
SKU: 1140727
8 pJ to 80 nJ pulse energy sensor, rep. rate to 10000 pps, 325 to 900 nm spectra range, 10 mm diameter active area.
J-10Si-HE Quantum Energy Sensor
SKU: 1150146
60 pJ to 775 nJ pulse energy sensor, rep. rate to 10000 pps, 325 to 900 nm spectra range, 10 mm diameter active area.
J-10Ge-LE Quantum Energy Sensor
SKU: 1140408
200 pJ to 600 nJ pulse energy sensor, rep. rate to 10000 pps, 800 to 1700 nm spectra range, 10 mm diameter active area.
EnergyMax-USB J-50MB-HE Energy Sensor
SKU: 1191444
USB-enabled, 1.6 mJ to 2J pulse energy sensor, rep. rate up to 300 pps, MaxBlack coating with 0.19 to 12 µm spectral range, 50 mm diameter active area.
EnergyMax-USB J-50MB-LE Energy Sensor
SKU: 1191443
USB-enabled, 400 µJ to 500 mJ pulse energy sensor, rep. rate up to 300 pps, MaxBlack coating with 0.19 to 12 µm spectral range, 50 mm diameter active area.
EnergyMax-USB J-25MB-HE Energy Sensor
SKU: 1191442
USB-enabled, 850 µJ to 1J pulse energy sensor, rep. rate up to 1000 pps, MaxBlack coating with 0.19 to 12 µm spectral range, 25 mm diameter active area.
