Compact thermopile sensor with UV coating for measuring pulsed & CW lasers between 5 mW and 2W. Direct RS232 interface.

Key Features:

·      5 mW to 2W range

·      19 mm diameter active area

·      UV coating

·      0.15 to 1 µm spectral range

·      Convective air-cooled

·      Direct RS232 interface

·      ISO 17025 accredited

This PowerMax-RS PM2X sensor is a compact laser power sensor intended for measuring lasers up to 2W. It incorporates a UV absorber coating that is optimized for use at ultraviolet wavelengths. Spectral compensation is available from 157 nm to 1064 nm.

The sensor is terminated in an RS232 cable that interfaces directly to a PC or industrial controller. DB25 (PN 1098457 and USB direct (PN 1257617) models are available.
