LM-2 IR Semiconductor Power Sensor
LM-2 IR Semiconductor Power Sensor
SKU
1098342
UOM
Each
10 nW to 10 mW power sensor, germanium optical sensor, 800 to 1500 nm spectral range, 5 mm diameter active area.
Price
$1,070.00 USD
Details
Low power germanium semiconductor power sensor for measuring CW lasers between 10 nW and 10 mW.
Key Features:
- 10 nW to 10 mW range
- 5 mm diameter active area
- Germanium detector
- 800 to 1800 nm spectral range
- Fiber adapters available
- ISO 17025 accredited
LM-2 high-sensitivity optical sensors are ideal for measurement in the nW to low mW level. An optional 1000:1 attenuator is available (PN 1098318) to support operation up to 5 Watts. SMA-type (PN 1098589) and FC/PC-type (PN 1098339) fiber optic adapters are available.
The sensor is terminated in a SmartSensor DB25 cable and is directly compatible with LabMax meters. For compatibility with other catalog meters choose the OP-2 VIS model (PN 1098416).
Specs
General
Cable Type
LM DB-25
Power Range
10 nW to 10 mW
Active Area Diameter
5 mm
Wavelength Range
800 nm to 1550 nm
Detector
Germanium
Wavelength Range (micrometers)
0.8 to 1.5
Window
None
Diffuser
None
Calibration Uncertainty (%)(k=2)
±4.5
Power Linearity (%)
±1
Spectral Compensation Accuracy (%)
±1.5
Calibration Wavelength (nanometers)
800 to 1550 nm
Cable Length (meters)
1.8
Maximum Power Density (watts per square centimeter)
0.5
Resolution (nanowatts)
1
