Free-Space Faraday Isolator, 2 mm Clear Apt., 405 nm, Waveplate, TORNOS Compact

Free-Space Faraday Isolator, 2 mm Clear Apt., 405 nm, Waveplate, TORNOS Compact

SKU 110-25025-0013
UOM Each

The TORNOS Compact Faraday isolators provide high transmission in the forward direction while strongly attenuating light traveling in the reverse direction, protecting lasers from the adverse effects of back reflections. Available in the VIS and NIR.


Price $1,095.00 USD


Details

Our TORNOS Compact devices deliver industry-best laser reliability and performance. Some common applications for the TORNOS Compact are the elimination of frequency instability in single frequency lasers such as laser diodes and OPSLs, the prevention of mode-hopping in external cavity diode lasers, and the elimination of parasitic oscillations due to ASE in amplified laser systems.

These devices offer:

  • Compact size with a 25 mm long, 20 mm Diameter
  • Design Wavelength of 633nm
  • Isolation of greater than 33 dB
  • Transmission greater than 95%
  • Waveplate to accommodate output polarization matching the input polarization.

The TORNOS Compact isolators contain optically-contacted polarizing beam splitter cubes resulting in high transmission as compared to other available isolators.

The TORNOS Compact’s industry-leading high transmission results in more photons for your application. This allows diodes to be run at lower currents extending diode lifetime. The compact design makes it highly suitable for OEM integration.

Buy now, contact Coherent to order your TORNOS Compact Isolator today.

Specs

General

Product Family
Isolator
Center Wavelength (nm)
405
Range Wavelength (nm)
10
Maximum Power (W)
5
Maximum Wavelength (nm)
410
Transmission (%) Minimum
90
Clear Aperture (mm)
2
Isolation (dB) Minimum
30
Minimum Wavelength (nm)
400
Dimension, Length (millimeters)
25
Dimension, Height (millimeters)
12
Dimension, Length (inches)
0.99
Dimension, Height (inches)
0.47
